It feels like there's something of a mechanical keyboard renaissance recently, with boutique brands producing some stunning keyboards with unique designs and advanced features for surprisingly little money. That's why this column exists, to highlight bits of tech that might not fit elsewhere but nonetheless deserve a mention.
#CUBE FLIP AFTER EFFECTS FULL#
In this situation using the Overlays setting Face Orientation can help as it tints surfaces based on their orientation, inwards or outwards.I've been lucky enough to test out a bunch of weird and wonderful tech, but I don't always get a chance to share my discoveries in a full review or roundup. If Backface Culling is disabled (off) it can be difficult to determine which way a given surfaces is pointing because both front and back of the mesh are the same. To disable, repeat, select Overlays » Face Orientation.ĭesign note: if X-Ray ( Alt + Z) is active for any of the Viewport Shading modes, Wireframe, Solid etc., Face Orientation won’t work. Everything will immediately tint blue/red based on their orientation. To use, click the Overlays button upper-right of the 3D View and from the menu select Face Orientation – Overlays » Face Orientation. To assist determining which way a face might be pointing, especially if Backface Culling is not disabled in Viewport Overlays or Viewport Shading options (depending on the viewport display mode) or a given materials Settings properties, Blender 2.8+ includes an option to colour tint faces based on their orientation, RED for surfaces pointing inwards and BLUE for those pointing outwards, making it much easier to see at a glance what’s going on, which then allows for individual faces to be flipped or recalculated as needed. For Blender 2.8+ this is no longer the case, Recalculate Inwards and Recalculate Outwards forceably re-orientate selections based on the option selected, either in or out but not both.įor instances where surfaces are randomly facing one way or the other, or there are too many to select and manually process, use Recalculate Inwards/Outwards to force everything to face the same direction, in or out, regardless – make a selection (individual, group or all) then click the Mesh menu, Normals then Recalculate Inwards/ Outwards.
Here select Normals » Recalculate Outside to flip faces/selections outwards, or Normals » Recalculate Inside to invert selections inwards – Mesh » Normals » Recalculate Outside/Inside.ĭesign note: in previous versions of Blender Recalculate tended to orientate faces randomly depending on the predominance of inwards or outwards facing surfaces prior to use. To do this and force the orientation in one direction or the other, in Edit Mode select the entire mesh ( A) and access the Mesh menu. The option to flip or invert faces is an Edit Mode option only (accessible only when editing meshes), click Mesh » Normals » Flip with an individual face or group selected.Īs an alternative to selectively inverting faces, or re-orientating a large mixed selection so everything points in one direction, inwards or outwards, use Recalculate Outside ( Shift + N) or Recalculate Inside ( Shift + Ctrl + N) options. The highlighted inverted face/s will immediately invert based on their current orientation.ĭesign note: when selecting errant faces using vertices or edges make sure all component elements are included to the degree that the inverted faces highlight. Alternatively use Alt + N to access the Normals context menu then select Flip. To access the option and/or correct an inside-out or inverted face, first select the errant mesh element in Edit Mode (using vertex, edge or face) and from the Mesh menu upper-left click Normals then Flip from the options that appear – Mesh » Normals » Flip. As the option is now context sensitive it only appears as a menu option in Edit Mode.ĭesign note: the Mesh menu is specific to Edit Mode and does not appear unless that particular editing context is active.
In newer versions of Blender the previously available Tool Shelf buttons Flip Direction and Recalculate, typically used to flip inverted surfaces that made meshes appear inside-out, have been moved to the main Mesh menu upper-left of the 3D View.
